IDEON AUDIO MASTER AYAZI DAC

From: $5,900.00

The jack of all trades

The Ayazi mk2 DAC is designed and fine-tuned specifically to reveal the musical magic encoded in the numbers, that are stored within the digital medium. Sound reproduction with exceptionally broad dynamic range, ultra-low distortion and low noise, accurate sound stage, and musical congruity.

We used the device in many different high-end systems and set-ups as it is intended to be the jack of all trades for digital-to-analogue conversion, to be used anytime, anywhere…

A high-performance DAC

No frills construction: solid and functional, the Ayazi as one reviewer put it, “probably sets the sonic performance benchmark for DACs costing double or more its asking price”, encompassing what we started out to do: to offer the experience of the musical event, a sound you wont believe for its price. With the Ayazi, style follows function and budget. The result: when it comes to DACs the Ayazi is the affordable reference!

Input Protection

The USB input comprises Ideon Audio’s proprietary electrostatic protection circuit; the best way to fight against signal degradation and noise is to keep it at bay before it enters the signal!

Asynchronous Dual Clock Input

Pushing jitter and the noise floor to vanishingly low levels to achieve phase-correct sound, and dynamics.

Femto clock architecture.

Pushes jitter and noise floor below perceptible levels in our circuit. Two high quality CCHD-957 oscillators by Crystek.

Over Engineered, Top of the Line Power

We not only need abundance of power, we need clean power, especially devoid of hi-frequency noises, electrical interferences, and similar performance compromising distortion.

Using top of the line regulators and hi-end audiophile capacitors, discrete and ultra-stabilised power feeds, the Ayazi declares its own war on extraneous electrical & digital noise, achieving unparalleled dynamics and clarity in its class.

We believe we have a sonic winner!

DIGITAL INPUTSUSB type 2 and above, SPDI/F
OUTPUT FULL SCALE2.0V RMS
FREQUENCY RESPONSE10Hz-25kHz (+/- 0.5dB)
SNR (DC to 20kHz)>112dB
CROSSTALK-110dB
SNR (A WEIGHTED 20HZ-20KHZ)>130dB on all outputs
THD+N (1kHz FS 96 kS/s)<0.002%E
USB INPUTTransfer mode: Asynchronous (dual clock) Device class: Type 2 or above Bit depth: 32 bit Sampling rates: 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz
DIMENSIONS (W X H X D)29cm X 17cm X 8cm
SPDIF / COAXIAL INPUTBit depth: 24 bit Sampling rates: 44.1, 48, 96, 192 kHz
CONTROLSOn/off switch, led indicator USB / SPDI/F input, sync led indicator
POWER REQUIREMENTS230 / 110 V AC, 1A, 20W max
OPERATING TEMPERATURE0-35˚ C
RELATIVE HUMIDITY5-95% non-condensing
OUTPUTStereo unbalanced impedance: 250 Ω
